Komputer stand alone Link Engine Managment 124-1000 G4+ Thunder

The Thunder is Link biggest, most advanced ECU yet.

The Thunder is designed for high end applications requiring maximum performance, flexibility and tuning control. The Thunder has more inputs, more outputs and more features than any other Link ECU.

The Thunder has all the features found on other LinkECU's plus onboard 3 axis accelerometer, two EGT thermocouple inputs, two Onboard Lambda Controllers and 2 x E-throttle Controllers.

If it is Direct Injection you are after, consider the Force GDI.

Inputs:

• 16 x Digital inputs (6 are high speed differential type for ABS sensors etc)
• 4 x Temperature inputs
• 16 x Analog inputs
• 2 x Trigger inputs
• 2 x Knock inputs
• 2 x LSU 4.9 Wideband lambda sensor inputs
• 2 x K Type Thermocouple inputs

Outputs:

• 8 x Peak and Hold injection drives
• 8 x Ignition drivers
• 18 x Auxiliary outputs (unused fuel and ignition drives can be used as additional Aux outputs)
• +5V Sensor power supply
• +8V Sensor power supply

Communications:

• 2 x CAN bus
• 1x Serial (RS232) connection
• 1x USB tuning connection

Advanced features not found on the Xtreme or Fury:

• 2 x Onboard digital wideband lambda controllers, no separate box required. Higher accuracy, simple setup and long sensor life are some of the advantages compared to a separate analog input wideband device.
• 2 x Fully programmable E-throttle controls complete with capability of gear shift throttle blip and antilag (for engines with 2 electronic throttle bodies).
• 2 x K type thermocouple EGT inputs – direct connection of EGT sensors with no extra interface box.

Physical:

• Dimensions: 180mm(L) x 210mm(W) x 40mm(H) (without looms)
• Mass: 1060 gram
