Wilwood 120-12070-BK MC4 Mechanical Parking Brake 1-pot caliper 0.81"/14" (left hand, black)
Wilwood's MC4 Mechanical Parking Brake Caliper is a multi-use, cable-operated brake caliper that combines high output performance with simplicity in design and construction, and is the perfect solution for vehicle applications requiring a separate, mechanically actuated parking brake caliper. Available calipers are built to accept rotors from .310” to 1.10” thick by part number, with an 11.00” - 14.00” diameter range, the MC4 combines an efficient die-cast body with a forged billet anvil for superior strength under load yet is lightweight at only 3.30 (2.95 without pads) pounds. Supplied with each caliper are our Composite Metallic (CM) high-friction, high static-hold brake pads and are pre-fitted with noise-canceling shields.
Engineered with noise-dampening features for quiet, rattle-free operation, the MC4 sliding caliper includes a steel bracket for convenient mounting. Available in both right-hand and left-hand construction, the caliper’s lever cartridge can be clocked in three positions for optimum positioning and ease of cable routing. The 1.19” aluminum piston is fully dust booted to keep moisture and debris out. Each caliper is fitted with a cable return spring, and the mechanical lever accepts a .310” diameter barrel-ended parking brake cable*. The convenient manual adjuster requires no special tools, allowing incremental adjustment to compensate for pad and rotor wear. MC4 calipers are available with either black, silver or red high-gloss, high-temp, brake fluid resistant powder coat and feature Wilwood’s signature logo.
Features:
- Strong yet lightweight (about 3 pounds) diecast and forged aluminum calipers with a steel mounting bracket
- Available with mounting plates in 2.00” offset holes or 4.75” centered holes in line with caliper body
- Left and right-handed cable pulls available, each clockable in three locations for optimum positioning and ease of cable routing
- New powersports calipers in rotor widths for 0.25” and 0.39” discs are finished with durable Type-III hard anodized coating
- Wider rotor width calipers for 0.81” and 1.10” discs are available in gloss red or black powder coat finish, with the 1.10” also in a durable Type-III hard anodized finish
- High static-hold Sintered Metallic SM compound brake pads
