TI Automotive (Walbro) BKS1001 E5LM brushless fuel pump kit with PWM (pulse-width modulation) controller (E85 compatible) 550LPH
Easy return of products within 14days
The BKS1001 is the next generation of our popular BKS1000 high pressure direct-fit fuel pump kit. Now with PWM (pulse-width modulation) control, you’ll enjoy a true three-step controller with functions for 100% duty cycle, 50% duty cycle by grounding the command wire, and full PWM command by wiring the input to a 100Hz battery level PWM signal. More customization at the controller level means more power for your ride.
The BKS1001 offers more power, more torque, and more speed while supporting up to 1000+ HP. Matched controller with simple power and ground operations for easy maintainability. The controller features sealed electronics for weather resistance.
- Fuel: GAS OR FLEX (E85)
- Horsepower: 650 - 1000
- Flow @ 276 kPa: 400 lph - 550 lph
- Flow @ 40 psi: 145 gph (550 LPH)
- Max System Pressure (psi): 112
- Max System Pressure (kPa): 772
- Inlet Diameter: 39 mm
- Pump Type: In-Tank Pump Kit
Producer
Product code
WAL BKS1001
Warranty
Flow
550 LPH
Working pressure
2.41 bar (35 psi) - 7.72 bar (112 psi)
Maximum power
1000 KM
Fitment place
In tank
12 months guarantee
12 months guarantee
