Garrett 898199-5001W GT2260S Stage 1 (485 KM) turbocharger Audi TT, TTS, A3, S3, VW Golf, Golf GTi, Golf R Mk7 2014-2018
For: Volkswagen / Audi 2.0L TSI MK7 2014 – 2018
OEM part numbers replacement:
- IS12 turbo (OEM 06K124713L)
- IS20 turbo (OEM 06K145874M)
- IS38 turbo (OEM 06K145722H)
POWERMAX™ DIRECT FIT PERFORMANCE TURBOCHARGER
Stage 1 and Stage 2 Turbochargers:
- Stage 1 Part number: 898199-5001W Supports up to 485 BHP (362kW)*
- Stage 2 Part Number: 898200-5001W Supports up to 600 BHP (447kW)*
Garrett PowerMax™ turbocharger upgrades for the Volkswagen and Audi MK7 2.0L TSI engine platform is engineered to increase engine performance while maintaining OEM installation specifications. Stage 1 (485 HP*) and Stage 2 (600 HP*) upgrades maximize efficiency and air flow compared to the OEM turbocharger. High temperature, Mar-M alloy turbine wheel and twin scroll stainless steel turbine housings are rated for up to 1050° C. These turbochargers are fully assembled with a calibrated electronic actuator and ancillary components for direct OEM fitment.
WARNING: Maximum allowable turbocharger speed is 185krpm (Stage 1) | 165krpm (Stage 2). The use of this product above max turbocharger speed is at the owner’s risk, and can result in damage and premature failure. To protect the turbocharger from overspeed when operating, a speed sensor port is machined into the compressor housing for the fitment of speed sensor part numbers 781328-0003 (includes sensor and gauge), and 781328-0004 (includes speed sensor). Speed sensors sold separately.
Stage 1 Features:
- Direct-Fit Stage 1 Upgrade
- 485HP | 362kW (flywheel) power capability (on-vehicle results)
- 47mm compressor inducer, 60mm compressor exducer
- 50mm turbine inducer, 45mm turbine exducer
- GT2260S turbocharger
- Audi A3, S3, TT, TTS
- VW Golf Base, AllTrack, GTI and R
- Complete assembly with calibrated electric actuator and ancillary components for OE fitment
- +17% flow compared to IS38 turbo (stock Golf R)
- GTX Gen II compressor wheel aero
- Modern gasoline turbine wheel aerodynamics constructed of Mar-M alloy rated for up to 1050C
- Stainless steel turbine housing rated for up to 1050C
- Fully machined speed sensor port
- Latest generation of journal bearing rotor group
- 360-degree thrust bearing –reinforced for application
Stage 1 Part number: 898199-5001W Supports up to 485 HP (362kW)*
Stage 2 Features:
- Direct-Fit Stage 2 Upgrade
- 600HP | 447kW (flywheel) power capability (on-vehicle results)
- 54mm compressor inducer, 67mm compressor exducer
- 54mm turbine inducer, 49mm turbine exducer
- G25-660 turbocharger
- Audi A3, S3, TT, TTS
- VW Golf Base, AllTrack, GTI and R
- Complete assembly with calibrated electric actuator and ancillary components for OE fitment
- +59% flow compared to IS38 turbo (stock Golf R)
- G-Series compressor wheel aerodynamics for maximum horsepower
- G-Series turbine wheel aerodynamics constructed of Mar-M alloy rated for up to 1050C
- Stainless steel turbine housing rated for up to 1050C
- Fully machined speed sensor port
- Ball-bearing
Stage 2 Part Number: 898200-5001W Supports up to 600 HP (447kW)*
