Turbocharger Borg Warner AirWerks S300SX3 90° 177283 T4 Single Scroll A/R 0.88

For: universal

Borg Warner Airwerks turbochargers are designed for the competitive motorsports market as well as drivers retrofitting a naturally aspirated engine or looking for a little more performance from a factory turbocharged car.

Engineered specifically for drag racing, pulling and road racing, AirWerks turbochargers have earned a reputation as robust, brute-force induction systems. Looking for a no-frills replacement? Want to upgrade your turbocharger? Working with limited space? BorgWarner’s AirWerks turbochargers are the perfect go-to product for many applications.

With a twin hydrodynamic journal bearing design, AirWerks turbochargers feature an effective high-pressure ratio compressor stage, extended-tip technology and a high-efficiency turbine stage. The configuration provides ultra-fast response and more than 70 PSI of boost.

The AirWerks S300SX3 is available with few different turbine housing configurations:

• For 80 mm Turbine Wheel:
• 0.88 A/R T4 undivided - P/N: 177211
• 0.91 A/R T4 twinscroll - P/N: 177208
• 1.00 A/R T4 twinscroll - P/N: 179905

• For 76 mm Turbine Wheel:
• 0.88 A/R T4 undivided - P/N: 177210
• 0.91 A/R T4 twinscroll - P/N: 177207
• 1.00 A/R T4 twinscroll - P/N: 177209

Features:

• Twin hydrodynamic journal bearings
• Extended tip technology compressor wheel
• Twin scroll turbine housing options available
• Adjustable compressor and turbine housing orientation
• Compressor cover recirculation grooves
