Garrett 836028-5003S GT3076R turbocharger (super core)

  • Garrett 836028-5003S GT3076R turbocharger (super core)
  • Garrett 836028-5003S GT3076R turbocharger (super core)
  • Garrett 836028-5003S GT3076R turbocharger (super core)
  • Garrett 836028-5003S GT3076R turbocharger (super core)
Producer: Garrett
Product code: GAR 836028-5003S
Warranty: No warranty
887,75 EUR
859,87 EUR
/ PCS

Easy product returns

Buy a product and check it in your own time, at home.
You can return the product without providing a reason within 14 days.
Show details
14 days for a return
Your satisfaction is very important to us, therefore you can make a return without providing a reason within 14 days.
No stress and worry
Thanks to the integration with cheap returns you can purchase without stress and be sure that the return process will be hassle free.
Easy returns wizard
All returns processed by our shop are managed in a easy-to-use returns wizard which gives you the ability to send a return parcel.

Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.

Features:

  • Original GT Series aerodynamics
  • Internally wastegated turbine housing
  • Non wategated turbine housings available
  • Ball bearing configuration with water cooled CHRA
  • V-band turbine housing options

Garrett GT3076R turbine housing options:

  • 0.63 A/R T3 (external WG) P/N 740902-0009
  • 0.82 A/R T3 (external WG) P/N 740902-0008
  • 1.06 A/R T3 (external WG) P/N 740902-0007
  • 0.61 A/R V-Band (external WG) P/N 740902-0036
  • 1.01 A/R V-Band (external WG) P/N 740902-0035
  • 0.63 A/R T3 (internal WG) P/N 771300-0006 (Wastegated turbine housing does not include bolts, clamps, or actuator)
  • 0.82 A/R T3 (internal WG) P/N 771300-0005 (Wastegated turbine housing does not include bolts, clamps, or actuator)
  • 1.06 A/R T3 (internal WG) P/N 771300-0004 (Wastegated turbine housing does not include bolts, clamps, or actuator)
Tech specs:
General
Producer:
Garrett
Series:
GT
Power range:
310-525 KM
Engine capacity:
2.0-3.5 l
Bearings:
Dual ball bearing with water cooling
Warranty:
12 months
Compressor side
Compressor wheel:
Steel
Compressor inlet:
103.6 mm (4")
Compressor wheel outer diameter:
76 mm
Compressor wheel inducer diameter:
57 mm
Compressor outlet:
50.8 mm (2")
BOV:
No
Turbine side
Turbine wheel:
Steel
Exhaust inlet:
Turbine housing sold separately
A/R:
Turbine housing sold separately
Turbine wheel outer diameter:
60 mm
Turbine outlet:
Turbine housing sold separately
Wastegate:
Turbine housing sold separately
Boost control solenoid:
Turbine housing sold separately
