Motec 14103 PDM30 power distribution module

MoTeC’s 30 output Power Distribution Module (PDM15) is designed to provide electronically switched power to the various electrical systems in the vehicle such as motors, lights and solenoids, and electronic devices such as ECUs and data acquisition systems.

The module replaces conventional relays, fuses and circuit breakers, simplifying wiring and reducing weight while increasing reliability.

BASIC SPECIFICATIONS
Outputs
8 x 20 A outputs - 20 A continuous, 115 A transient (typical)
7 x 8 A outputs - 8 A continuous, 60 A transient (typical)
Inputs
16 x Switch inputs
Communications
1 x CAN
Diagnostic Information
Output current and voltages
Input voltages
Error status
Physical
Connectors
1 x 34 pin waterproof connector
1 x 26 pin waterproof connector
1 x M6 stud
Case size 108 x 128 x 39 mm
Weight 260 grams
