Garrett 836023-5004S GT2560R T25 A/R 0.64 WG turbocharger
Easy return of products within 14days
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
Features:
- Original GT Series aerodynamics
- Internally wastegated turbine housing
- Sold as a complete turbo (includes turbine kit and actuator)
- Ball bearing configuration with water cooled CHRA
General
Producer
Garrett
Series
GT
Power range
170-270 KM
Engine capacity
1.4-2.2 l
Bearings
Dual ball bearing with water cooling
Warranty
12 months
Compressor side
Compressor wheel
Steel
Compressor inlet
53 mm (2 bolts)
Compressor wheel outer diameter
60 mm
Compressor wheel inducer diameter
46 mm
Compressor outlet
38.50 mm (3 bolts)
BOV
No
Turbine side
Turbine wheel
Steel
Exhaust inlet
T25 Single Scroll
A/R
0.64
Turbine wheel outer diameter
53 mm
Turbine outlet
T25 5 bolt
Wastegate
Built-in
Boost control solenoid
No
