Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger

Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
Garrett 836026-5013S GT2860RS T25 A/R 0.86 WG turbocharger
ProducerGarrett
Product codeGAR 836026-5013S
1 212,77 EUR
1 176,83 EUR
/ pcs / incl. 23% VAT
Easy return of products within 14days

Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.

Features:

  • Original GT Series aerodynamics
  • Internally wastegated turbine housing
  • Sold as a complete turbo (includes turbine kit and actuator)
  • Ball bearing configuration with water cooled CHRA
  • V-band turbine housing options

Garrett GT2860RS turbine housing options:

  • 0.64 A/R T25 (internal WG) P/N 827690-0005
  • 0.86 A/R T25 (internalWG) P/N 827690-0004
  • 0.57 A/R V-Band (external WG) P/N 827690-0001
  • 0.72 A/R V-Band (external WG) P/N 827690-0002
Producer
Product code
GAR 836026-5013S
Warranty
General
Producer
Garrett
Series
GT
Power range
250-360 KM
Engine capacity
1.8-3.0 l
Bearings
Dual ball bearing with water cooling
Warranty
12 months
Compressor side
Compressor wheel
Steel
Compressor inlet
76 mm (3")
Compressor wheel outer diameter
60 mm
Compressor wheel inducer diameter
47 mm
Compressor outlet
50.8 mm (2")
BOV
No
Turbine side
Turbine wheel
Steel
Exhaust inlet
T25 Single Scroll
A/R
0.86
Turbine wheel outer diameter
54 mm
Turbine outlet
T25 5 bolt
Wastegate
Built-in
Boost control solenoid
No
