Quaife QKE10R 6-speed sequential gearkit Lotus Elise, Exige 1.8 2ZZ-GE with PG1 gearbox
QKE10R delivers ultra-fast sequetial gearshift technology for owners of Lotus Elise / Exige models using the PG1 gearbox. QKE10R features a replacement Quaife outer gearbox tailcase which houses six power loss minimising straight-cut, close-ratio gears and a compact, drum-style sequential gearchange mechanism. This combines with an open face dog design to ensure an ultra-rapid, positive sequential gear shift on QKE10R
QKE10R to retains the original PG1 bellhousing half of the transmission casing, plus the stock Lotus clutch, differential, driveshafts and mounting points. This enables easy installation of the QKE10R sequential gearkit into numerous Lotus models and potentially the MGF and MG ZR / ZS.
QKE10R is supplied with gear ratios suited to motorsport requirements and three final drive options to optimise top speed for the needs of competition.
Key features of the QKE10R Lotus Elise / Exige PG1 six-speed sequential gearkit include:
-Six straight-cut, close-ratio gears with motorsport suited final drive ratios
-Ultra fast sequential gearshift
-Retains stock Lotus Elise / Exige clutch, diff, driveshafts and mounts
-Optional Quaife ATB and LED digital gear readout available
Available Gear Ratios:-
3.100 2.067 1.421 1.048 0.870 - Drag Set (straight-cut / spur)
3.100 2.067 1.611 1.333 1.136 - Rally Set (straight-cut / spur)
2.417 1.611 1.263 1.000 0.852 - Race Set (straight-cut / spur)
2.400 1.600 1.261 1.038 0.857 - Road/Track Helical Set
Available Final Drive Ratios
4.357 / 4.750 Straight-cut (spur) 4.750 Helical
PLEASE NOTE: An optional Quaife automatic torque biasing helical gear limited slip differential is also available for QKE8J, in two variants; QDF9U for Honda K20A engined cars running standard driveshafts and (QDF17U) for drag orientated Honda’s using 28 spline Driveshaft Shop Pro-Level driveshafts.
